Relacart HR-31S, mikrofonní 1-kanálový přijímač

doprava zdarma

skladem



Dostupnost: Do 5 dnů
Číslo produktu: 13055200
EAN kód: 4026397537000
Cena bez DPH : 6 884 Kč (289 EUR)
Cena s DPH (21 %):
8 330 Kč (350 EUR)

do košíku:
  ks
Multifrequency wireless receiver with high-quality true diversity reception Real-time monitoring and data management using RWW PC software 2 license-free frequency ranges: 731-790 MHz (10 EU countries) and 823-832 MHz (14 EU countries) 731-790 MHz (requires license in Germany) is lockable and offers 244 fixed frequencies (10 frequency banks with up to 25 frequencies each) 823-832 MHz (license-free in Germany) offers 48 fixed frequencies (8 frequency banks with up to 7 frequencies each) 292 frequencies manually adjustable in steps of 25 kHz within 68 MHz switching bandwidth Parallel operation of up to 12 systems is possible without any interference Pilot tone technology (PLL) and noise squelch for interference-free operation Operation range with line of sight approx. 80 meters Automatic frequency scan (AFS) finds interface-free channels Infrared interface for easy and error-free channel transfer to transmitters via infrared signal LCD for battery status of the transmitter, antenna A/B, RF reception level, AF audio level and frequency Serial RS-485 interface for connecting a computer with the optional USB/RS-485 converter U485 Up to 32 units can be linked with network cables Lock function avoids accidental changing of settings XLR and 6.3 mm jack output 2 detachable BNC antennas allow for use with the R-14D antenna divider Matching transmitters optionally available: hand-held microphone (HR-31S), pocket transmitter (T-30) Delivery includes practical transport bag with jack cable and power unit Durable metal housing 483 mm rack installation possible with supplied mounting brackets License-free and approved in large parts of the EU (please check on a country-by-country basis

Technické parametry
Přenosová frekvence UHF 731 - 790 MHz, 823 - 832 MHz (krok 25kHz)
Šířka pásma 68 MHz
Deviation 45 kHz
S/N > 108 dB
Dosah 80 m
Audio výstup XLR, balancovaný a 6,3 Jack, nebalancovaný
Antenní vstup 2x BNC
Rozměry 224 x 43 x 206 mm, 1U
Velikost balení 40 x 31 x 7 cm
Hmotnost balení2.2 kg
